Linear spacer Druzack

OPIS PRODUKTU

Mounting washer with thread Halteplatten

Reusable mounting washer designed for threaded sleeves. The washer is attached to the formwork, and after concreting, it can be unscrewed. Washer height is 10 mm.

Article No.	Fits into	Washer ∅ (mm)	For fastening screws	Packaging (pcs)
9823	M8 blue	58	–	100
9825	M10 yellow	58	M4	100
9826	M12 red	58	M6	100
9827	M16 black	58	M10	100
9828	M20 yellow	58	M10	100
9829	M24 blue	58	M10	100
9831	M30 black	58	–	100

OPIS PRODUKTU

Mounting anchor Gewindehülse – W

Type of thick-walled, sturdy, galvanized steel anchor with a metric thread. The increased tensile strength is achieved thanks to the flat and bent end. Used for securing doors and windows.

Article No.	Type	Hole	Length (mm)	Packaging (pcs)
20567	WM 8 – 40	M8	40	100
20568	WM 10 – 50	M10	50	100
20569	WM 12 – 60	M12	60	100
20570	WM 12 – 70	M12	70	100
20571	WM 16 – 60	M16	60	100
20572	WM 16 – 70	M16	70	100
20573	WM 16 – 90	M16	90	100

OPIS PRODUKTU

Mounting washers Stapefix – T

Washers are used to arrange prefabricated elements vertically and protect them from often occurring stains during the curing of concrete on wooden beams. The washers are equipped with supporting pins on both sides and holes for tensioning straps. Standard version made of gray plastic.

Article No.	Type	Dimensions (mm)	Packaging (pcs)
20708	T	90 x 40	500

Dodatkowe informacje: W miejscach założonych podkładek mogą wystąpić niewielkie uszkodzenia. Aby zapobiec przesuwaniu ładunku należy stosować dodatkowe zabezpieczenia w transporcie.

OPIS PRODUKTU

Mounting washer with thread Klebefix

Mounting washer holds in position the flood anchors leaving them in a 5 mm recess. It is attached to the steel formwork using adhesive. After removing the formwork, the mounting plate can be unscrewed.

Article No	Type	Thread	Plate ∅ (mm)	Packaging (pcs)
20550	M8	M8	50	500
20551	M10	M10	50	500
20552	M12	M12	50	500
20553	M16	M16	50	500
20554	M20	M20	50	500
20555	M24	M24	50	500
